Description
1508 Measuring Probe
The new probe 1508 is extremely compact and suits universal applications of multi-gauging stations and inspection fixtures. These incremental probes or linear encoders are ideal in applications requiring high accuracy over long range measurements. The incremental design also makes setup simpler because there is no calibration needed. Just setup the probe, zero the gage, and start measuring! These probes use standard m2.5 metric threaded contact points.
Specification
| Output signals | 1 Vss |
| Scale | DIADUR glass scale with incremental graduation |
| Scale division | 20 µm (0.000787 in) |
| Measuring range | 12 mm (0.472 in) |
| System accuracy | ± 1.0 µm (± 39.37 µin) |
| Position | any |
| Measuring force vertical, downwards | 0.6 to 1.8 N (0.135 to 0.405 lbf) |
| Measuring force vertical, upwards | 0.4 to 1.6 N (0.09 to 0.36 lbf) |
| Measuring force horizontal | 0.5 to 1.7 N (0.1125 to 0.3825 lbf) |
| Admissible measuring speed | 1.2 m/s (47.244 in/s) |
| Admissible transverse force | 0.8 N (0.18 lbf) |
