Shimpo FGE-200XY 200 lb (100 kg) Capacity Digital Fore Gauge FGE-200XY

(No reviews yet) Write a Review

$815.00

Brand: Shimpo Instruments
SKU:: FGE-200XY
UPC:

Current Stock:

Quantity:

Adding to cart… The item has been added

Description
0 Reviews

Description

200 lb Capacity Digital Force Gauge

Features

1000 Hz Sample Rate combined with +/-0.2% F.S. accuracy provides fast sampling producing great resolution and more accurate results
Three mode operation: Track, Peak & Auto-Peak
180° Auto-reversible display, tension/compression icons, and dual printed keypad allows usage as a portable gauge or mounted upside down on a test stand
Programmable High & Low Limits allow for instant visual and audible indication of pass or fail testing
1000 point data collection capability can be viewed on display, sent to optional printer, or uploaded to software package via USB or RS-232 Serial Port for further analysis
Rugged, ergonomic die cast aluminum construction allows usage in demanding applications
Comparator output function provides user with easy Pass/Fail testing system integration capabilities
Multi-language and engineering units selection provides flexible user comfort
Field Calibration capability eliminates need to send to lab
Calibration Certificate included along with popular adapter attachments
Free Data logging/graphing software available for free download on website

Digital Force Gauges with 180° reversible display & dual labeled keypad for both push, pull applications. The Series FGE-XY Digital Force Gauges combine a rugged, ergonomic and compact design with exceptional accuracy to provide a solid force testing instrument. These instruments are utilized in a variety of applications such as, incoming quality inspection, finished goods testing, R&D or almost any portable or force stand testing requirement. Simple one button adjustment alters units, while pressing the peak button quickly produces the highest recorded value during the test. The 180° reversible display combined with the adjustable force direction and dual labeled keypad enable the FGE-XY to excel in both compression and tension applications in any direction. Typical applications include wallboard, wire pull, wire crimps, trigger pull, brake pedal, aerospace ceramic, springs, food ripeness, corrugated paper strength, blister pack, medical component, muscle strength, ergonomic testing, adhesives, syringe plunger, needle sharpness and many more.

Specification

Model	FGE-200XY
Capacity	200 lb, 100 Kg, 1000N
Resolution	0.1 lb, 0.1 Kg, 1N
Accuracy	±0.2% F.S. @ 73°F (23°C)
Display	4-Digit LCD, 0.5? (12 mm) high, Units 0.29? (7 mm). Reversible. Minus sign for tension
Display Update	0.05, 0.1, 0.2, 0.3, 0.5, 1 sec
Sampling Rate	1000 Hz
Overload Capacity	200% of F.S. (200 lb.: 150% F.S.)
Power	Rechargeable Ni-MH battery or universal AC adapter/charger (100 240 VAC, 50/60 Hz)
Auto Power Shut-Off	Yes (not active if adapter/charge is in use)
Battery Charge	12 hours (when fully charged)
Recharge Time	Approximately 18 hours (when fully discharged)
Temperature Limits	32 104°F (0 40°C)
Dimensions	5.8 x 3 x 1.5? (147 x 75 x 38 mm)
Product Weight	Approx. 1.1 lb (500 g)
Certification	CE, RoHS
Included Accessories	AC adapter/charger, carrying case, hook, chisel, flat head, notched head, hanger, cone head, metric to inch thread adapter, extension rod
