AEMC Simple Logger® II Model AL834

AEMC AL834 Description

The AL834 Simple Logger® II (Bluetooth Edition) has two measurement ranges of up to 300 and 3000 Amps. Both the data logger housing and the current sensors are water resistant rated to IP 65. A selection of data storage modes, as well as data sampling rates is user programmable through the DataView® application software provided. Up to 1,000,000 measurements can be stored in internal nonvolatile memory.

The Model AL834 is powered by four C cell alkaline batteries capable of providing six months or longer recording time. Data storage rates as fast as 8 per second are user programmable. Communication to the DataView® software is accomplished through wireless Bluetooth technology. The Bluetooth adapter, provided, facilitates this communication link.

Features

• Includes four integral AmpFlex^® flexible current probes that will measure up to 3000A TRMS with 0.1A resolution
• Dual range 300/3000A user selectable per channel
• 64 samples per cycle
• Programmable storage rates from 125ms to 1 day
• 4 user selectable storage modes
• Stores up to 1,000,000 measurements in non-volatile memory
• Powered by standard Alkaline batteries for a period of 180 days or more
• Lightweight, compact, weatherproof
• 6 LED indicators quickly and clearly display logger status
• Wireless Bluetooth communication (Bluetooth Module included)
• Includes FREE DataView^® software for data storage, real-time waveform display analysis & report generation
• EN 61010-1; 600V CAT IV, 1000V CAT III

Applications

• Single/split phase and 3 phase monitoring
• Neutral and ground current monitoring
• Intermittent problem detection
• Harmonic current monitoring using DataView^® software
• Machine load monitoring
• Fault current detection
• Load profiling
