Hioki CT6845A AC/DC Current Probe, 500A, DC - 200 kHz

Hioki CT6845A Description:

The Hioki CT6845A AC/DC Current Probe can be connected directly to Hioki Power Analyzers and Memory HiCorders. The CT6845A can measure current in applications where it's not possible to cut lines, including testing of EVs on chassis dynamometers and evaluation of operational solar power systems. The CT6845A is designed to measure AC and DC currents of up to 500 A at a high level of accuracy and can be used to measure power with high accuracy as well as current.

Key Features:

• Current Range: 500A AC/DC
• Frequency Bandwidth: DC to 200 kHz
• 50 mm diameter max clamp opening (1.97 inch)
• Power supplied via the measurement instrument
• Automatic phase correction function
• Ideal for EV inverter evaluation and PV power generation PCS evaluation
• Single-handed operation and robust locking mechanism
• Ideal for use in environmental testing with broad -40°C to 85°C temperature range

Includes:

• 1 - CT6845A Current Probe
• 6 - Markup bands
• 1 - User's Manual
