Description
If you're looking for a magnetic-base indicator holder that is easy to use and offers fine adjustment, the Insize 6208-80E Magnetic Stand may be your solution. The Insize 6208-80E Magnetic Stand features an on/off switch that allows you to power it on or off as needed. This model comes with an articulating arm that can be moved into any position. The base has a magnetic design which keeps it firmly in place while allowing for smooth movement of the indicator. It also has a fine adjustment top feature that provides fine adjustments when necessary. If you want an easy way to hold your dial test indicators, look no further than the Insize 6208-80E Magnetic Stand.
Insize 6208-80E Specifications
- Item: Magnetic-Base Indicator Holder
- Magnetic Pull (Lb.): 176
- Base Size (In.): 1-31/32 W x 2-31/64 D x 2-11/64 H
- Rod Dia. (In.): 0.472
- Upright Post Dia. (In.): 0.472
- Includes: Low Locking Force
- For Use With: Dial and Electronic Indicators
- Finish: Powder Coated
- Switch Type: On/Off
- Construction: Steel
- Overall Length (In.): 16-9/64
- Features: Fine Adjustment, Dovetail groove
- Screw Type: Knob
- Step Type: V-Step
- Holding Power: 176 lbf
- Base Height: 2 13/64 in
- Fine Adjustment Position: Fine Adjust Top (FAT)
- Centering Arm Shank Size: 3/8 in Dia.
- Arm Type: Articulating
- Working Length of Post/Lower Arm: 5.669 in
- Base Width: 1 31/32 in
- Base Type: Magnetic
- Base Thread Size: M8 x 1.25
- Compatible Indicator Mounts: 3/8 in, 4 mm, 8 mm, Dovetail Mount
- Includes Snug: Yes
- Working Length of Snug/Third Arm: 2.95 in
- Working Length of Upper Arm: 4.921 in
- Magnet Type: On/Off Knob
- Maximum Reach: 13.976 in
- Base Length: 2 23/64 in
- Base Size: 2.362 in L x 1.969 in W x 2 1/5 in H
- Accessory Type: Magnetic-Base Indicator Holder
- Country of Origin (subject to change): China
