Mahr 2051669 SNAP GAGE, 4-5" CAPACITY, WITH 2034201
(No reviews yet)
Write a Review
Write a Review
Mahr
Mahr 2051669 SNAP GAGE, 4-5" CAPACITY, WITH 2034201
$2,047.50
- Brand
- Mahr
- SKU:
- 2051669
- Availability:
- In Stock
Description
Features:
- Patented "Channel Lock" design ensures parallelism across the entire adjustment range
- Adjustable centering stop
- Large, square hard metal measuring surface inclined to facilitate insertion of the testpieces
- All of the settings can be implemented using the enclosed Allen wrench
- Other measuring surface geometries on request
Specification
| Product type | EDI-300P-5 |
| Application range mm | 101.6 - 127 |
| Measuring span in mm | 0.5 mm |
| Measuring range in inch | 0.02 inch |
| Size of measuring surface in mm | 15,5 x 15,5 mm |
| Parallel error in µm | 4 µm |
| Measuring force | 18 N |
| Mounting hole for indicator | 0.375 inch |
| Dimensions | a 127 mm | b 251 mm | c 29 mm | d 180 mm | e 193 mm | |
 | |
Variety of applications for our products
