Description
Features:
- Patented "Channel Lock" design ensures parallelism across the entire adjustment range
- Adjustable centering stop
- Large, square hard metal measuring surface inclined to facilitate insertion of the testpieces
- All of the settings can be implemented using the enclosed Allen wrench
- Other measuring surface geometries on request
Specification
| Product type | OMI-300P-7 |
| Application range mm | 152.4 - 177.8 |
| Measuring span in mm | 0.5 mm |
| Measuring range in inch | 0.02 inch |
| Size of measuring surface in mm | 15,5 x 15,5 mm |
| Parallel error in µm | 4 µm |
| Measuring force | 18 N |
| Mounting hole for indicator | 0.375 inch |
| Dimensions | a 177.8 mm | b 303 mm | c 30 mm | d 213 mm | e 226 mm | |
 | |
