Mahr 4103071 16 EWR DIGITAL CALIPER,12"/300 W/OP,IP67,NO DEPTH ROD,W/FW
(No reviews yet)
Write a Review
Write a Review
Mahr
Mahr 4103071 16 EWR DIGITAL CALIPER,12"/300 W/OP,IP67,NO DEPTH ROD,W/FW
$488.25
- Brand
- Mahr
- SKU:
- 4103071
- Availability:
- In Stock
Description
Digital Caliper MarCal 16 EWRFeatures:
- High contrast digit display
- Locking screw above
- Lapped guideway
- Measuring blade for inside measurements
- Slide and beam made of hardened stainless steel
- Step measuring function
- Immediate measurements due to the Reference System
- Raised guideway for the protection of the scale
- Excellent resistance against dust, coolants and lubricants
- Dirt wipers are integrated in the slide
Specification
| MarCal 16 EWR | Art.-Nr. 4103071 | |
|---|---|
| Measuring range mm | 0 - 300 |
| Measuring range inch | 0 - 12" |
| Resolution mm/inch | 0.01 / .0005" |
| Standard | Factory standard |
| Friction wheel | |
| Error limit (mm) | 0.04 mm |
| Error limit inches | .0015" |
| Battery type | CR 2032 (3V Lithium) |
| Dimensions | a 14 mm | b 64 mm | c 19 mm | d 388 mm | e 16 mm | |
 | |
