Mahr 4150201 40 FC DIAL MICROMETER, 25-50MM CERAMIC FACES
$1,795.50
- Brand
- Mahr
- SKU:
- 4150201
- Availability:
- In Stock
Description
Micrometer with integrated dial comparator Micromar 40 FC
Features:
- Operating and display units with satin chrome finish
- Dial comparator is integrated in frame
- Adjustable tolerance markers
- Chrome plated steel frame, heat insulated
- Retraction of the movable anvil ensures maximum wear resistance
- Spindle and anvil are carbide-tipped
- Stainless spindle is hardened throughout and ground
- Locking device
- Constant measuring force
Specification
Micromar 40 FC | Art.-Nr. 4150201 | |
---|---|
Standard | Factory standard |
Measuring range mm | 25 - 50 |
Material Contact surface | ceramic |
Error limit µm | 2 µm |
Parallel error in µm | 1 µm |
Flatness in µm | 0.2 µm |
Spindle diameter | 7.5 mm |
Spindle thread pitch_mm | 0.5 mm |
Dial color | White |
Type of dial face | 65-0-65 |
Graduation value µm | 1 µm |
Measuring force | 9 N |
Measuring force (N) | 9 |
Error limit Ge (µm) | 1 µm |
Dimensions | a 174 mm | b 125 mm | c 30 mm | d 85 mm | e 56 mm | |
