Mahr 4332005 1010 T MILLIMESS, 0.01 MM GRAD DRIP-PROOF

(No reviews yet) Write a Review

$341.05

Current Stock:

Quantity:

Adding to cart… The item has been added

Description

Dial comparator Millimess 1010 T

Factory standard

IP 54

Measuring range mm: ±0.25 mm

Graduation value mm: 0.01

Package contains: case

Features:

Large, high contrast dial face
Adjustable tolerance markers
Lockable fine adjustment screw
Shockproof movement
Mounting shank and measuring spindle are both made of hardened stainless steel
Measuring spindle is mounted in a high precision ball guide for minimal hysteresis
Resistant to lateral forces (side play) acting on the measuring spindle
Maximum sensitivity and accuracy are ensured by the jeweled movement in conjunction with the precision gears and pinions
Box type protective housing
Constant measuring force
Measuring spindle can be retracted with either a screw in cable release or with a lifting knob


Measuring range mm	±0.25
Product type	1010 T
Standard	Factory standard
IP protection category	IP 54
Graduation value mm	0.01
Type of dial face	25-0-25
Error limit Ge (µm)	7 µm
Error limit Gges (µm)	8 µm
Error limit Gt (µm)	4 µm
Measuring value hysteresis fu (µm)	2 µm
Repeatability fw (µm)	2 µm
Measuring force	1 N
Scale diameter	50 mm
Dial color	White
