Description
Features
Basic Units
- Sturdy, T-shaped base which is made from a special cast iron
- Extremely stable
- Fine adjustment, consisting of a strong, rigid parallel springassembly
- Support arm has a rotation lock, height of the arm via the toothed rack is adjustable
- With fine adjustment, consisting of a strong, rigid parallel spring assembly
- Excludes indicating instrument, excludes plate
Specification
| Working range | 0 - 210 mm/ 0 - 8.2 inch |
| Fine adjustment range | ± 0.2 mm/ 0.0078 inch |
| Weight | 19 kg/ 41.89 lb |
| Mount dia. | 3/8 inch |
