Mahr 4451005 840 FH INDICATING SNAP GAUGE 30-80MM/1.18"-3.0",WOODEN CASE

(No reviews yet) Write a Review

$3,003.00

Current Stock:

Quantity:

Adding to cart… The item has been added

Description

Indicating snap gage Marameter 840 FH

Measuring range mm: mm

Package contains: flat contact point 903 (steel), spanner DIN 902-3,5, wooden case, excludes indicator

Features:

Rugged, forged steel frame with heat insulators
Measuring spindle is mounted in long guideway with lever controlled retraction
Measuring and anvil spindle have precision tapered bores for mounting interchangeable anvils (with accessory 40 He)
Anvil spindle can easily be fine adjusted
Constant measuring force as a result of built-in spring, eliminating user influence
Maximum wear resistance due to non-contact positioning in conjunction with carbide tipped measuring faces


Product type	840 FH
Application range mm	30 - 80
Measuring span in mm	2.5 mm
Repeatability fw (µm)	1 µm
Measuring force	7.5 N
Dimensions	a 7.5 mm \| b 193 mm \| c 110 mm \| d 10 mm \| e 60 mm \| f 103 mm \| g 13 mm \| h 13 mm \| k 28 mm \| l 59 mm \| n 2.5 mm \|
