Mahr 5318457 COLUMN, 1840PE FEDERAL 10000:1 HI MAG - FEDERAL AIR TOOLING

(No reviews yet) Write a Review

$3,622.50

Brand

SKU:

5318457

Availability:

In Stock

Description

Features:

When using pneumatic compact column measuring instruments we recommend using a pressure controller and supply filter (see accessories) at all times
Clear, three-color analog light bar display of warning and tolerance limits
Backlit, two-line LCD for displaying measuring values, help texts and units of measurement
1-channel
RS-232 interface
Analog output
3 digital inputs for measurement start, master measurement, etc.
3 digital outputs for good, reject, rework classification, measuring time, etc.
Dynamic measurements: Max, Min, Max-Min, Max+Min, Average
The Millimar S1840 column measuring instrument can either be programmed via the integrated membrane keypad using the menu-driven interface or via the configuration software for MS Windows®
1-point or 2-point master measurement
Password block in setup mode

Millimar S 1840 PE/F \| Art.-Nr. 5318457
Display	101 LED elements, 3 color
Product type	S 1840 PE/F
Scale reading	± 10, 30, 100, 300, 1000, 3000, 10000 ?m
Range and text display	7 digit LCD, 14 segments, alphanumeric
Digital display	7 digit LCD, 7 segments
Range of analog display inches	± .0001'' , ± .0003" , ± .001'' , ± .003'' , ± .01'' , ± .03'' , ± .1'' , ± .3'' , tolerance related
Tolerance display	Via color change of the analog display
Compatibility	Federal
Measuring combination	+A, -A
Features	1
Programs	1
Test steps	1
Dynamic functions	Max, Min, Max-Min, (Max+Min)/2, Average
Configuration	PC, keyboard
Zero setter	electrical
Error limit	0.5 - 1%
Error limit, digital display	+/- 1 place
Error limit, analog display	1% (101 LEDs)
Data interface	RS-232C , wireless
Hardware interfaces	RS-232C , I/O interface
Control inputs	3 optocoupler inputs, 24 V, 10 mA
Control outputs	3 optocoupler outputs, 24 V, 100 mA
Analog output	1 V/mm
Energy supply	Power source , 230 V/115 V; 50/60 Hz
Power consumption	20 VA
IP protection category	IP 43
Relative humidity non-condensing	80 %
Operating temperature Min	0 °C
Operating temperature Max	45 °C
Temperature coefficient	0.005 µm/°C
Product weight	1.6 kg

Miscellaneous

Label	Art. no.	For measuring instrument	Data interface	Hardware interfaces	Cable length	Product type	Frequency band	Radio range	Number of connectable wireless receivers for e-Stick	Number of connectable transmission modules for e-Stick	System requirements:
Data connection cable RS232C	7024634	Digimar 817 CLM Millimar C1208, C1216, 1240, C1245, S1840, S1841, X1715, X1745, 832	RS-232C , Null modem	RS-232C , Null modem	3 m
Adapter cable RS-232-USB Millimar - USB	4102331	Millimar C1208, C1216, 1240, C1240, C1245, S1840, S1841, X1715, X1741, 832 (in conjunction with cable 7024634)	USB	RS-232C , USB	0.2 m	Millimar - USB
Transmitter RS-232 e	4102233	Millimar C1208, C1216, C1245, S1840 Digimar 817 CLM	RS-232C	RS-232C		RS-232 e	2400 MHz	up to 6 m (20 ft)
Receiver e-Stick	4102230	Transmission modules 16 EWe, 2000 e, RS232 e	USB			e-Stick	2400 MHz	Up to 6 m	1	8	IBM AT compatible PC , CD- / DVD-drive , MS Excel from version 97 onwards , MS Windows 7 , USB-interface from version 1.1 , minimum 10 MB free hard disk space
