Megger 1006-752 MIT481/2 Insulation Tester LG2

(No reviews yet) Write a Review

$1,123.50

Brand: Megger
SKU:: 1006-752
UPC:
Availability:: In Stock

Current Stock:

Quantity:

Adding to cart… The item has been added

Description
0 Reviews

Megger MIT420/2 Description

MIT481/2-LG2 adds additional features required for engineers working on more demanding applications. Functions such as PI and DAR, capacitance measurement and a greater range of test voltages increase the suitability for many applications. MIT481/2-LG2 insulation tester features a variable range to allow any intermediate voltage from 10 V to 1000 V in 1 V steps, when testing specific test voltages that do not appear in the standard ranges is required. Continuity testing is now significantly faster, and a single autoranging 0.01 Ω to 1.0 MΩ function replaces the "ohms" and "kOhms" ranges. Retained are the 200 mA and 20 mA test options. The instrument is over-moulded for increased protection and has an IP54 weatherproof rating.

Features:

Designed for Electrical and Industrial testing
Insulation testing up to 1000 V and 200 GΩ range
Stabilised insulation test voltage
Single range, faster continuity testing from 0.01 Ω to 1 MΩ
Adjustable insulation test voltage from 10 V to 1000 V
600 V Trms AC and DC voltage measurement
Test result storage
Live circuit detection and protection
Rechargeable options for mains and car charging
CAT IV 600 V and IP54

Specifications

Test voltage	50 V, 100 V, 250 V, 500 V, 1000 V
Display range	Analogue: 1 GΩ full scale
Resolution	0.1 kΩ
Short circuit/charge current	2 mA +0% -50% to EN 61557-2 (2007)
Open circuit voltage insulation	-0% +2% ± 2V
Test current	1 mA at min. pass value of insulation to a maximum of 2 mA max.
Leakage	10% ±3 digits
Voltage	3% ±3 digits ±0.5% of rated voltage
Timer control	60 second countdown timer
Continuity measurement	0.01 Ω to 999 kΩ (0 to 1000 kΩ on analogue scale)
Open circuit voltage	5 V ± 1 V
Test current	200 mA (–0 mA +20 mA), (0.01 Ω to 4 Ω)
Polarity	Single polarity (Default) / Dual polarity (configurable on setup).
Lead resistance	Null up to 9.00 Ω
Voltage range	AC: 10 mV to 600 V TRMS sinusoidal (15 Hz to 400 Hz) DC: 0 to 600 V
Frequency measurement range	15 Hz - 400 Hz
Frequency measurement accuracy	±0.5% ± 1digit (100 Hz to 400 Hz unspecified)
Storage capacity	>1000 test results
Power supply	6 x 1.5 V cells type IEC LR6 (AA, MN1500, HP7, AM3 R6HP) Alkaline 6 x 1.2 V NiMH rechargeable cells may be used
Battery life	3000 insulation tests with duty cycle of 5 sec ON /55 sec OFF @ 1000 V into 1 MΩ

Applications:

Electrical installations
Cable testing
Motor testing
Automotive
ESD
Panel building
Avionics
Maintenance
