Mitutoyo 115-216 25-50/.01MM TUBE MIC W/SA
$158.00
- Brand
- Mitutoyo
- SKU:
- 115-216
- Availability:
- In Stock
Description
A Mitutoyo non-digital tube micrometer equipped with spherical anvil and spindle tip for making wall thickness measurements on tubes and pipes. A ratchet stop guarantees repeatable measurement.
Features
| Digital/Analog: | Analog |
| Inch-Metric: | Metric |
| Range: | 25 - 50 mm |
| Graduation: | 0,01 mm |
| Maximum Permissible Error J MPE: | ?3 ?m |
| Measuring face: | Spindle and anvil: carbide-tipped, micro-lap finish (115-1xx, 115-2xx) spindle: carbide-tipped, micro-lap finish anvil: hardened steel (115-3xx) |
| Anvil / Spindle: | Type F, spherical anvil and spindle SR=4 mm |
| Mass: | 240 g |
| Measuring spindle: | With spindle lock, ?6,35 mm, spindle pitch 0,5 mm |
| Scale: | Thimble and sleeve satin chrome finish, ?18 mm |
| Delivered: | Including box, setting standard (from 25 mm upward), key |
