Mitutoyo 122-126 MIC, BLADE, 1-2", 0.0001", RANGE
(No reviews yet)
Write a Review
Write a Review
Mitutoyo
Mitutoyo 122-126 MIC, BLADE, 1-2", 0.0001", RANGE
$287.00
- Brand
- Mitutoyo
- SKU:
- 122-126
- Availability:
- In Stock
Description
A mitutoyo non-digital micrometer provided with blade-ended non-rotating spindle and anvil to enable measurement of shrouded features, such as grooves and keyways. A ratchet stop guarantees repeatable measurement.Specification
| Inch-Metric: | Inch
|
| Range: | 1 - 2
|
| Graduation: | 0,0001"
|
| Maximum Permissible Error J MPE: | ±0,00015"
|
| Parallelism: | 0,00015"
|
| Digital/Analog: | Analog
|
| Measuring face: | Carbide-tipped or hardened steel spindle and anvil
|
| Anvil / Spindle: | Type A, hardened steel t=0.75 mm
|
| Measuring spindle: | ø8 mm, non-rotating, spindle pitch 0,5 mm
|
| Scale: | Thimble and sleeve satin chrome finish, ø18 mm
|
| Measuring force: | 3 - 8
|
| Delivered: | Including box, setting standard (from 25 mm upward), key
|
| Mass: | 300
|
