Mitutoyo 368-163 HT-12R

Description

A non-digital 3-point Mitutoyo bore micrometer with titanium-coated measuring pins. The 3-point design enables stable measurement through automatic centering. The maximum measuring depth can be increased by 100mm using an optional extension rod if required. Ratchet stop guarantees repeatable measurement. Steel setting rings (optional) are available for accurate setting prior to measurement.

Specification

Range:	10 - 12
Graduation:	0,001 mm
Maximum Permissible Error J MPE:	?2 ?m
Scale:	Thimble and sleeve satin chrome finish, Up to 12 mm : ? 17 mm Over 12 mm : ? 23 mm
Measuring spindle:	Spindle pitch 0,5 mm
Measuring face:	Titanium coated tungsten carbide taper: tungsten carbide
Measuring method:	3-point
Delivered:	Including box, key, certificate of inspection
Digital/Analog:	Analog
Mass:	60
Inch-Metric:	Metric
