Mitutoyo 511-415 Mechanical Blind Hole Bore Gauge, 10-16" Range, Without Indicator

(No reviews yet) Write a Review

$396.90

Current Stock:

Quantity:

Adding to cart… The item has been added

Features

Measures ID closer to the bottom of holes with high accuracy of 4 µm
A pendulum guide structure permits the slide of the gauge for easier measurements without sacrificing accuracy
A two-point contact system detects geometry anomalies such as ovalness and taper
Large, innovative designed hollow grips are easier to hold and reduce heat transfer from the operator for better accuracy
The gauge stem diameter is 0.3" (8 mm)
Interchangeable anvils are constructed of alloy steel with carbide-tipped measuring faces for added accuracy and durability

Applications

Measuring Range	15 to 35 mm
Accuracy	Wide-range accuracy: 4 µm Repeatability: 1 µm Adjacent error: 1 µm
Effective Stroke of Contact Rod	1.2 mm
Number of Anvils	11
Number of Spacers	1
Units	Metric
Contact Point	Carbide-tipped
Stem Diameter	0.3" (8 mm)
