Description
- Its I/O control function enables tolerance judgement evaluation (3 or 5 steps) or serial BCD output function.
- Dynamic measurement possible with simplified analog output.
Specification
| Resolution: | 0,0001/0,0005/ 0,001/0,005/0,01 |
| ZERO SET: | Yes |
| Power supply: | Terminal block (M3 screws) 12 to 24 V DC, 6W or less (500 mA max.) external supply, AC-adapter is not included |
| PRESET: | Yes |
| BCD output: | Yes |
| External HOLD: | Yes |
| MAX?/?MIN?/?Difference measurement: | Yes |
| Mm?/?inch switching: | Yes |
| Max. input frequency: | 1,25 MHz (2-phase square wave), response speed depends on gauge specification |
| Number of inputs: | 1 |
| Input signal type: | Differential square-wave |
| Applicable gauge: | LGF, LGK, LGB, LG, LGM, LGH (excluding LGF-Z with reference point, LGH with 0.01 ?m resolution), LG100 with connector adapter plug 21HZA195 |
| Gauge inputs: | 1 |
| Power supply: | Terminal block (M3 screws) 12 to 24 VDC, 500 mA (max.) via an external supply |
| Output I/O: | Yes |
| Analogue output: | Yes 2.5v + counting value X voltage resolution (25mV/2.5V): Full scale 0-5V |
| Delivered: | AC adapter, AC cable and terminal connecting cables are not included. Please see accessories below. |
| Mass: | 400 |
| Digimatic data output: | Yes |
| Counting direction switchable: | Yes |
| External PRESET / ZERO: | Yes |
| Display: | Green LED display, 6 digit plus sign |
| Tolerance judgement display: | LED display (3 steps : Amber, Green, Red/5 steps : Amber, Amber flashing, Green, Red flashing, Red) |
