Mitutoyo 547-212 Series 547 ABSOLUTE Digimatic Depth Gauge, 0 to 200 mm, 0.01 mm resolution
(No reviews yet)
Write a Review
Write a Review
Mitutoyo
Mitutoyo 547-212 Series 547 ABSOLUTE Digimatic Depth Gauge, 0 to 200 mm, 0.01 mm resolution
$499.70
- Brand
- Mitutoyo
- SKU:
- 547-212
Description
This ABSOLUTE Digimatic Indicator Depth Gauge offers you the following benefits:- It is equipped with the ABSOLUTE Digimatic Indicator ID-C.
- It has a hardened, precision ground and micro-lapped reference face on its base.
Specification
| Digital/Analog: | Digital |
| Range: | 0 - 200 |
| Stroke: | 12.7 |
| Accuracy: | ± 20 µm |
| Base flatness: | 5 µm |
| Lock function: | Yes |
| Scale: | Capacitance type ABSOLUTE linear encoder |
| PRESET: | Yes |
| Alarm: | Low voltage, counting value composition error, overflow error, tolerance limit setting error |
| Battery life: | Approx. 7000 hours |
| ABS / INC (INC ZERO): | Yes |
| DATA (output with cable) / HOLD (display value): | Yes |
| Power supply: | 1 battery SR-44 |
| Counting direction switchable: | Yes |
| Inch-Metric: | Metric |
| Mass: | 340 |
| Digimatic data output: | Yes |
| Measuring force: | ? 1.5 |
| Contact point: | Carbide ball |
| GO/±NG judgement: | Yes |
| Calculation function (with formula): | Yes |
| Delivered: | Including Box and extensions 10, 20, 30 (2 pcs.), 100 mm, contact point 21JAA224 |
