RKI 61-0198RK-02 Sensor, IR Carbon Dioxide (CO2) 0-5,000 ppm, non explosion proof direct connect, replaceable sensor
Write a Review
RKI Instruments
RKI 61-0198RK-02 Sensor, IR Carbon Dioxide (CO2) 0-5,000 ppm, non explosion proof direct connect, replaceable sensor
- Brand
- RKI Instruments
- SKU:
- 61-0198RK-02
Description
The RKI 61-0198RK-02 IR Carbon Dioxide Sensor is highly reliable and very cost effective for the detection of common gas hazards. This is the optional non-explosion proof version for use in non-hazardous atmospheres. The direct connect sensor can be used in 2 different ways. The sensor can be mounted directly to the controllers as a complete stand alone system, or it can be mounted to explosion proof junction boxes for remote detection. Plus, it is suitable for indoor or outdoor placement. An optional stainless steel junction box is available for corrosive environments. All of the direct connect sensors are designed to specifically interface with RKI Beacon 110, 200 and 410 controllers.
Features
- For accurate carbon dioxide (CO2) detection
- Equipped with a replaceable infrared sensor
- Mounts directly to the controller or to the explosion proof junction box
- Optional stainless-steel junction box
- Sensor only
Specification
?| Sensor | Infrared |
| Measuring Range | 0 to 5,000 ppm |
| Lower Detectable Limit (LDL) | 2% of full scale |
| Response Time (T-90) | 30 seconds or less |
| Life Expectancy | 5 years plus with normal service |
| Approvals | Class 1 Div 2 |
