RKI 65-2434RK Carbon Monoxide (CO) sensor / transmitter in plastic enclosure (non explosion proof)
Write a Review
RKI Instruments
RKI 65-2434RK Carbon Monoxide (CO) sensor / transmitter in plastic enclosure (non explosion proof)
- Brand
- RKI Instruments
- SKU:
- 65-2434RK
Description
The RKI 65-2434RK Carbon Monoxide Sensor/Transmitter in plastic enclosure (non-explosion proof) is designed for the detection of carbon monoxide and hydrogen sulfide. The electronics are protected inside a plastic enclosure to avoid damage from mechanical abuse, water, dust or corrosion, while the transmitter itself can be used either indoors or in semi-enclosed areas. The only tools required for calibration are a voltmeter, screwdriver and calibration gas, and the zero and calibration functions are performed by adjusting potentiometers on the amplifier board. The amplifier board has test jacks for the connection of a voltmeter for calibration purposes, and field calibration can be performed easily and quickly by 1 person for user convenience.
Features
- Water- and dust-resistant housing ensures long-lasting use
- Detects carbon monoxide and hydrogen sulfide
- Long life sensors withstand wear and tear
- Compact design for convenience
- Capable of performing zero and calibration functions
- Amplifier board comes with test jacks
Specification
?| Operating Voltage | 11 VDC to 30 VDC |
| Max Current Draw | 25 mA (2 wire system) |
| Signal Output | 4 mA at 0 ppm CO, 20 mA at 300 ppm CO |
| Response Time | 30 seconds to 90% of concentration |
