RKI 65-2649RK-CH4-4 M2A, IR Methane (CH4) LEL 0-100% sensor / transmitter with j-box, remote detector and calibration adapter/splash guard, cULus version
(No reviews yet)
Write a Review
Write a Review
RKI Instruments
RKI 65-2649RK-CH4-4 M2A, IR Methane (CH4) LEL 0-100% sensor / transmitter with j-box, remote detector and calibration adapter/splash guard, cULus version
$1,820.00
- Brand
- RKI Instruments
- SKU:
- 65-2649RK-CH4-4
Description
With four operating modes, the stand alone sensor operates with or without a controller.
Features
- Direct digital readout with OLED cold temperature display
- 4-20 mA and digital Modbus outputs standard
- 2 fully programmable alarm relays and fail relay
- Non-intrusive calibration via magnetic wand
- Explosion proof construction
- Patented water repellent sensor cover
- User friendly setup, push buttons and OLED menus
- Long-life sensors (2 + years typical)
Applications
- Petrochemical plants
- Refineries
- Water and wastewater treatment plants
- Pulp and paper mills
- Manufacturing facilities
- Automotive
- Semiconductor plants
- Chemical plants
Specification
| Sensors | Infrared |
| Measuring Range | 0 to 100% LEL |
| Version | UL |
| Weather Resistant | Patented water repellent sensor coating |
| Display | Alphanumeric OLED display 8 characters per line; 2 lines for gas concentration readout User-friendly calibration and setup |
| Alarm Indication | Visual LEDs. Alarm 1, Amber; Alarm 2, Red; Fail, Red |
| Relative Humidity | 5 to 95% RH non-condensing |
| Operating Voltage | 10 to 30 VDC |
| Enclosure | Explosion proof for Class I, Div 1, Groups B, C, D |
