RKI 73-0052-ASH3 SC-8000 toxic gas detector,arsine,0-0.20 ppm,alkaline type

(No reviews yet) Write a Review

$2,419.00

Brand

RKI Instruments

SKU:

73-0052-ASH3

Description
0 Reviews

Description

Offers a compact, lightweight, durable, waterproof, and intrinsically safe design makes the SC-8000 Portable Toxic Gas Monitor the industry standard for portable toxic gas detection.

Features

Real-time detection with ppm range
Large digital display with backlight
Loud alarm buzzer with 95 dB
Two steps adjustable alarm volume
Easy and simple operation
Compact size and light weight
ATEX intrinsically safe design EXia IIC T4
Water and dust resistant IP67
Datalogging standard
Self diagnosis system
Zero/span adustment (deman zero/auto zero selectable)
Indication to show energizing (pilot indicator and pump driving indicator)
IrDA communication, data logger (interval, alarm trend, station ID control)
Peak value/average value display, buzzer selector switch (two steps high/low)
Bump test function

Applications

Semiconductor plants
Petro chemical/chemical plants
Refineries
Gas plant/gas supplier services
Utilities
Personal monitoring
Hazmat response
Utlilities
Water/wastewater treatment

Specification

Arsine (AsH3)	Range:0 to 0.2 ppm Resolution: 0.001 Alarms: A1: 0.05 A2: 0.1
Alarm Types	Gas alarm: Latching, 2 alarm Failure alarm: Flow failure, sensor failure, battery failure, circuit failure, calibration failure, setting current failure
Alarm Display	Lamp: LED's flash Buzzer: Alternating high and low pitch (gas alarm), continuous sound (failure alarm) Display: Gas concentration on the display flashes (gas alarm), alarm message on display flashing (failure alarm)
Audible Alarm	95 dbB (A) at 11.81" (30 cm)
Sampling Method	Sample draw, approximately 0.5L/minute
Display	Digital LCD with auto backlight
Operating Temperature and Humidity	14 to 104Â°F (-10 to 40Â°C), humidity 20 to 88% RH (without condensing)
Ingress Proof Rating	IP-67
Power	Continuous operation: Lithium-ion battery: 25 hours, AA alkaline battery: 18 hours (3 hours charge time)
Safety Rating	Intrinsically safe; Exia IIC T4
Dimension	6 x 3.18 x 6.45" (154 x 81 x 164 mm)
Weight	2.42 lbs (1097.69 g)
