RKI GD-70D-CO-03 Smart transmitter,GD-70D,CO (carbon monoxide),0-300 ppm w/ESU-23 sensor
(No reviews yet)
Write a Review
Write a Review
RKI Instruments
RKI GD-70D-CO-03 Smart transmitter,GD-70D,CO (carbon monoxide),0-300 ppm w/ESU-23 sensor
$1,395.00
- Brand
- RKI Instruments
- SKU:
- GD-70D-CO-03
Description
Features
- Plug and play smart sensors retain calibration and sensor data
- Common platform (main unit/sensor/pump) for all detection methods
- Universal main unit (all sensor types)
- Multifunctional sensor unit (new intelligent sensor)
- No internal tubing (main unit)/no coil (pump)
- Front access, no tool required, easy sensor and pump replacement
- Large size LCD screen
- Various communication methods available (4-20mA, NT and PoE)
- Minimal maintenance cost through enhanced troubleshooting firmware functions
- Small mounting space
- Environmentally friendly
Applications
- Gas detection
Specification
| Communication | 4-20 mA DC |
| Detection Principle | Different type depending upon sensor unit and detectable gas |
| Sampling Method | Sample drawing types (auto-adjustment of flow rate) 0.5/min ±10% |
| Display | White backlight |
| Gas Alarms | First alarm: Red Second Alarm: Red Fault Alarm: Yellow |
| External Output | Relay contact output for each alarm |
| Self Diagnostic Function | System failure, sensor failure, flow failure, communication error NT/ET/analog |
| Data logging | Event history, alarm history, calibration history Alarm trend: 180 sec before/after 1st alarm |
| Operation Temperature and Humidity | 32 to 104°F (0 to 40°C), 30 to 70% RH (non-condensing) |
| Mounting | Wall-mounting base plate by 2 or 3 screws |
| Sampling Tubing | 4 x 6 mm PTFE tubing recommended |
| Bushing | Cable type varies depending on communication method |
| Dimensions | 2.8 x 4.7 x 5.9" (70 x 120 x 150 mm) |
| Weight | 2 lbs (0.9 kg) |
