Starrett BORE GAGE, DIAL, .107"-.266", .0001" GRADS

Features

• These gages are also available with electronic indicators by special order
• Useful for controlling approach to tolerance without removing the workpiece from a machine
• Sets furnished in attractive, protective case
• Each set consists of a dial indicator, a body and actuating rod, two adjusting wrenches and the probes
• The split-ball contact is self-centering, the two-point contact detects hole geometry problems like taper, bell-mouth and out-of- roundness
• Interchangeable probes are hard chrome plated and polished
• All probes come complete with actuating rod
• Reads to .0001"

Specifications

• Made in America: Yes
• Range (in): .107 - .266"
• Graduations (in): .0001"
• Approximate Measuring Depth (in): 13/16"
