UEi HUB8 SMART REFRIGERANT PROBES DELUXE KIT

Description

HUB8 Includes Only:

• Manual (Eng)
• Batteries 14; 4 (AAA), 10 (AA)
• Pouch/Cases
• Pipe Clamp Probe
• 45-degree brass adapter
• Wireless Hygrometer probe
• Pressure probes

Wireless Vacuum Gauge Probe:

• Range 0-20,000 Microns
• 1-micron Resolution, ±5% reading ±5 microns accuracy
• Oil contamination and sensor failure detection
• Instant warm-up and response time
• 1/4" Nickel-plated flare fitting
• 45° coupler

Wireless Pressure Probes:

• Pass through refrigerant port for easily adding or recovering refrigerant from the system without disconnecting probes.
• 180° rotation for easy use in cramped spaces.
• Range 0 to 725 psig, resolution 0.1 psi.
• Accuracy 0.5%FS ( at25±3°C), total 1%FS

Wireless Pipe Clamps:

• Sensor is thermally isolated from ambient temperatures
• High accuracy thermistor provides better results than thermocouples and doesn t require field calibration.
• Slim design fits into tight spaces
• Range 32° to 176°F (0° to 80°C), resolution 0.1°F.
• Response time < 30 sec. Accuracy ±0.6°F (±0.3°C).

Wireless Hygrometer Probes:

• Slimmest 1/4" hygrometer probe means smaller drill holes.
• Magnetic mount and locking probe holds WHP1 to plenum for hands-free operation.
• Temp range: 32° to 140°F (0° to 60°C), Accuracy: ±0.5°F (±0.3°C).
• Relative Humidity: 0 to 100% (0.1% resolution, ±3% accuracy from 20 to 80% ±5% otherwise).

Wireless Outdoor Temperature Probe:

• Temperature range 32° - 180°F (0° - 82°C)
• Magnetic hanger allows for temperature measurement in direct air stream
• Compact light weight design

The Android version of the APP used with the HUB8 is on Google Play. The iOS version of the APP (1.3) used with the HUB8 is on The App Store.The HUB8 Smart Refrigeration Probes Deluxe Kit is the most complete and convenient wireless refrigeration probe kit today. The HUB8 makes it easier for to service and charge air-conditioning and refrigeration systems. The addition of the wireless Vacuum Gauge and Outdoor Thermometer probe integrates real-time Target Superheat, Evacuation and Rise Test calculations into the App. This provides a more accurate, efficiency and cost-effective charge on the system allowing all vacuum, refrigeration and air parameters to be viewed from one location.

Specification
