WINTER D81SIR1CSESF2N D81 THREADED SENSOR, 1", CARBON CENTRE, EPDM, SS PLATES, FILLED, SS WINCONNECT, 1/2" NPT
(No reviews yet)
Write a Review
Write a Review
U.S. Winter instruments
WINTER D81SIR1CSESF2N D81 THREADED SENSOR, 1", CARBON CENTRE, EPDM, SS PLATES, FILLED, SS WINCONNECT, 1/2" NPT
$1,542.21
- Brand
- U.S. Winter instruments
- SKU:
- D81SIR1CSESF2N
- UPC:
- 6.28311E+11
- Availability:
- In Stock
Winters, D81SIR1CSESF2N, D81 Isolation Ring, 1" Pipe I.D., Carbon Centre, EPDM Elastomer
Features:
- Unique WinCONNECT fitting allows for easy field removal of gauge or switch for calibration, repair or replacement without interrupting process flow
- Thicker break-resistant instrument stem
- Optional tees for installation of multiple instruments
- ASME B40.100 compliant
Application:
- This isolation ring is ideal for measuring pressures of viscous or slurry media, utilizing a flow-through system that eliminates clogging or pressure blocking from occurring.
- Designed for installation in water treatment facilities, mining and pulp & paper plants.
| Sensor Type | Threaded Connections |
| Pipe I.D. | 1" |
| Centre Section | Carbon Steel |
| End Plates | Stainless Steel |
| Elastomer (Sleeve) | EPDM (-20?F to 300?F) |
| Fill Fluid | Silicone (Standard) |
| Instrument Connection | 1/2" NPTF |
| A | 2.5" |
| B | 3.37" |
