WINTER PEM1320ZR PEM-ZR 1.5" 0/100 PSI/KPA 1/8" NPT BTM
(No reviews yet)
Write a Review
Write a Review
U.S. Winter instruments
WINTER PEM1320ZR PEM-ZR 1.5" 0/100 PSI/KPA 1/8" NPT BTM
$25.48
- Brand
- U.S. Winter instruments
- SKU:
- PEM1320ZR
- UPC:
- 6.28E+11
- Availability:
- In Stock
Winters, PEM1320ZR, PEM-ZR 1.5" Steel Gauge with 0/100 psi/kPa Scale Range
Features:
- Dampened movement minimizes eff ects of pulsation and vibration
- Most economical, all-purpose pressure gauge
- Friction bezel rings
- Black steel case
- Brass wetted parts
- ASME B40.100 compliant
- ?3-2-3% accuracy
- CRN registered
Applications:
- General purpose gauge for plumbing, heating, air conditioning, pneumatic, hydraulic, water tanks and air compressors
- Suitable for non-clogging and non-corroding media
| Case | Steel, painted black |
| Lens | 1.5" (40 mm) |
| Ring | 1.5" (40 mm) Steel, painted black |
| Socket | 1/8" NPT Bottom |
| Bourdon Tube | Phosphor bronze |
| Movement | Brass, StabiliZR dampened movement (silicone in sealed chamber) |
| Pointer | Aluminum, black |
| Welding | Silver alloy |
| Over-Pressure Limit | 25% of full scale value |
| Working Pressure | Maximum 75% of full scale value |
| Ambient/Process Temperature | -40?F to 150?F (-40?C to 65?C) |
| Accuracy | ?3-2-3% ANSI/ASME Grade B |
| Enclosure Rating | IP52 |
| Scale Range | 0/100 psi/kPa |
