WINTER PPC5398 PROCESS 4.5" 0/6,000 PSI/KPA 1/2" NPT BTM BR
(No reviews yet)
Write a Review
Write a Review
U.S. Winter instruments
WINTER PPC5398 PROCESS 4.5" 0/6,000 PSI/KPA 1/2" NPT BTM BR
$180.29
- Brand
- U.S. Winter instruments
- SKU:
- PPC5398
- UPC:
- 6.28311E+11
- Availability:
- In Stock
Winters, PPC5398, PPC Process Gauge, Brass, 1/2" Bottom, 0/6000 psi/kPa, Dual Scale
Features:
- Solid phenolic front and polypropylene pressure relief back safety case
- ?0.5% accuracy
- Micrometer adjustable pointer for ease in calibration
- Under and overload stops
- ASME B40.100 compliant
- CRN registered
Applications:
- Ideally suited for process, chemical, petroleum and power industries
- Suitable for non-clogging corrosive media
- Used where operator safety is a requirement
- Processes where pulsation and vibration exist (with liquid filling)
| Dial Size | 4.5"(115mm) white aluminum with black and red markings |
| Connection | 1/2"Bottom |
| Pressure range | 0/6,000 psi/kPa |
| Socket, Tube | Brass |
| Case | Black phenolic with pressure relief back, solid front, integral back flange |
| Ring | Phenolic |
| Pointer | Aluminum, anodized black, micrometer adjustable |
| Welding | Silver alloy |
| Working Pressure | Maximum 75% of full scale value |
| Enclosure Rating | IP65 |
