WINTER PTG6006 PTG SERIES 6" 0/300 PSI BRASS 1/4" BTM 0.25% ACC
(No reviews yet)
Write a Review
Write a Review
U.S. Winter instruments
WINTER PTG6006 PTG SERIES 6" 0/300 PSI BRASS 1/4" BTM 0.25% ACC
$952.09
- Brand
- U.S. Winter instruments
- SKU:
- PTG6006
- UPC:
- 6.28311E+11
- Availability:
- In Stock
Winters, PTG6006, PTG Series Test Gauge, 6", 0/300 Psi, Brass 1/4", Btm 0.25% Acc
Features:
- Highly accurate ?0.5% complete with calibration certificate traceable to NIST standards
- Mirrored anti-parallax dial
- Knife-edge pointer
- ASME B40.100 compliant
- CRN registered
Applications:
- Designed to be used where accuracy and repeatability are of prime importance
- Used in laboratories and instrument testing facilities
| Dial | White aluminum with black markings and mirror band for precise instrument readings |
| Lens | 4" (100mm): Polycarbonate 6" (150mm): Glass |
| Ring | AISI 304 SS |
| Socket | Brass |
| Connection | 1/4" NPT or 1/2" NPT standard, bottom |
| Bourdon Tube | Phosphor bronze |
| Movement | Brass |
| Pointer | Aluminum, anodized black, micrometer adjustable, knife-edge |
| Welding | Silver alloy |
| Over-pressure Limit | 30% of full scale value |
| Working Pressure | Maximum 75% of full scale value |
| Calibration Conditions | 68?F (?5.4?F), 20?C (?3?C) for ambient and process temperatures at atmospheric pressure |
| Ambient/Process Temperature | -4?F to 150?F (-20?C to 65?C) |
| Accuracy | ?0.5% ANSI/ASME Grade 2A |
| Enclosure Rating | IP65 |
