Winters 300 SERIES 8.5" SS 30"/100 PSI/KPA 1/4 BTM P3S6304
(No reviews yet)
Write a Review
Write a Review
U.S. Winter instruments
Winters 300 SERIES 8.5" SS 30"/100 PSI/KPA 1/4 BTM P3S6304
$1,045.74
- Brand
- U.S. Winter instruments
- SKU:
- P3S6304
- UPC:
- 6.28311E+11
Winters, P3S6304, P3S 8.5" Dial, 30"/0/100 PSI/kPa, 1/4" NPT Bottom Stainless Steel Gauge
Features:
- Heavy duty, highly accurate aluminum case gauge
- ?0.5% accuracy
- Brass or stainless steel internals
- Large, easy-to-read dial
- StabiliZR? dampened movement available on 4.5" (115mm) dial size
- ASME B40.100 compliant
- CRN registered
- 5 year warranty
Applications:
- Use on air, steam, oil, fresh water
- Boiler and control room
| Range | 30"/0/100 PSI/kPa Bottom |
| Dial | 8.5" (215mm) white aluminum with black and red markings |
| Case | Aluminum painted black |
| Front Flange | Aluminum painted black |
| Back Flange | Aluminum, painted black |
| Lens | Polycarbonate |
| Ring | Anodized aluminum |
| Socket | 316L SS |
| Connection | 1/4" NPT for ranges up to 600 PSI (4,137 kPa), |
| Bourdon Tube | 316L SS |
| Movement | 304 SS |
| Pointer | Aluminum, anodized black, micrometer adjustable |
| Welding | 316L SS TIG Argonarc |
| Over-Pressure Limit | 30% for pressures up to 600 PSI (4,137 kPa), 25% for pressures over 600 PSI to 1,400 PSI (4,137 kPa to 9,653 kPa), 15% for pressures over 1,400 PSI (9,653 kPa) |
| Working Pressure | Maximum 75% of full scale value |
| Ambient/Process Temperature | -40?F to 150?F (-40?C to 65?C) |
| Accuracy | ?0.5% ANSI/ASME Grade 2A |
| Enclosure Rating | IP52 |
