Winters 6" BRASS DIFF 0-15 PSI 1/4" NPT PDT8071
(No reviews yet)
Write a Review
Write a Review
U.S. Winter instruments
Winters 6" BRASS DIFF 0-15 PSI 1/4" NPT PDT8071
$1,558.26
- Brand
- U.S. Winter instruments
- SKU:
- PDT8071
- UPC:
- 6.28E+11
Description:
Winters, PDT8071, PDT 6" 0-15 PSI 1/4" NPT Bottom Brass Differential Pressure Gague
Applications:
- Single pointer to show difference from two pressure sources
- Typically used to measure pressure drops across a filter, pump or other equipment
Description & Features:
- Brass or stainless steel wetted parts
- Both conventional and balanced scale available
- ASME B40.100 compliant
- CRN registered
- 5 year warranty
Specification
| Case | Aluminum, painted black |
| Front Flange | SS |
| Back Flange | Black steel |
| Lens | Glass |
| Ring | 4.5" (115mm): SS 6" (150mm): Aluminum |
| Socket | Brass or 316 SS |
| Connections | 1/4" NPT standard |
| Scale | PSID only |
| Bourdon Tubes | Phosphor bronze or AISI 316 SS, independent, matched |
| Movement | Brass |
| Pointer | Aluminum (micrometer) |
| Welding | Tin/copper alloy for brass internals, TIG argonarc for SS internals |
| Over-Pressure Limit | 30% of full scale value |
| Working Pressure | Maximum 75% of full scale value |
| Ambient/Process Temperature | -40?F to 150?F (-40?C to 65?C) |
| Accuracy | +/-1% ANSI/ASME Grade 1A |
