Winters 6" SCHAEFFER GAUGE, 0/10 PSI/KPA, 1/2" BTM CONN PSG6105
(No reviews yet)
Write a Review
Write a Review
U.S. Winter instruments
Winters 6" SCHAEFFER GAUGE, 0/10 PSI/KPA, 1/2" BTM CONN PSG6105
$1,439.33
- Brand
- U.S. Winter instruments
- SKU:
- PSG6105
- UPC:
- 6.28E+11
Winters, PSG6105, PSG 6" 0/10 PSI/KPA 1/2" Bottom Connection Shaeffer Gauge
Applications:
- Used for low pressure corrosive media where diaphragm seal protection is needed
- Processes where low or high temperature will affect seal fill fluid
Description & Features:
- A combination pressure gauge and diaphragm seal forming one unique instrument that measures low pressures where protection from the process media is required
- Bottom connection only
- All stainless steel construction
- A variety of materials available
- ASME B40.100 compliant
- CRN registered
- 5 year warranty
| Dial | 4" (100mm), 6" (150mm) white aluminum with black markings |
| Case | 304 SS |
| Upper Flange | SS (neck and base movements) |
| Lower Flange | 316L SS bottom connection |
| Lens | Acrylic |
| Connection | 1/2" NPTM bottom (female optional) |
| Diaphragm Element | 316 SS, 316 SSl PTFE lined, or Tantalum |
| Movement | All SS - Push rod / connecting link and segment |
| Pointer | Adjustable pointer - aluminum |
| Wetted Parts | 316 SS |
| Ambient Temperature | -13?F to 150?F (-25?C to 65?C) |
| Process Temperature | 212?F (100?C) Maximum |
| Accuracy | +/-1.5% of full scale |
| Enclosure Rating | IP54 |
0 Reviews Hide Reviews Show Reviews
U.S. Winter instruments
Winters 6" SCHAEFFER GAUGE, 0/30 PSI/KPA, 1/2" BTM CONN PSG6305
$1,439.33
6" SCHAEFFER GAUGE, 0/30 PSI/KPA, 1/2" BTM CONN
U.S. Winter instruments
Winters 6" SCHAEFFER GAUGE, 0/15 PSI/KPA, 1/2" BTM CONN PSG6155
$1,439.33
Winters, PSG6155, PSG 6" 0/15 PSI/KPA 1/2" Bottom Connection Shaeffer GaugeApplications:Used for low pressure corrosive media where diaphragm seal protection is neededProcesses where low or high...
U.S. Winter instruments
Winters 6" SCHAEFFER GAUGE, 0/100 PSI/KPA, 1/2" BTM CONN PSG61005
$1,439.33
Winters, PSG61005, PSG 6" 0/100 PSI/KPA 1/2" Bottom Connection Shaeffer GaugeApplications:Used for low pressure corrosive media where diaphragm seal protection is neededProcesses where low or high...
U.S. Winter instruments
Winters 6" SCHAEFFER GAUGE, 0/300 PSI/KPA, 1/2" BTM CONN PSG63005
