Winters 90 SERIES 1.5"x1/8"NPT BACK 0/60 PSI/KPA P9S901401
(No reviews yet)
Write a Review
Write a Review
U.S. Winter instruments
Winters 90 SERIES 1.5"x1/8"NPT BACK 0/60 PSI/KPA P9S901401
$29.15
- Brand
- U.S. Winter instruments
- SKU:
- P9S901401
- UPC:
- 6.28E+11
- Availability:
- In Stock
Description:
Features:
- A general-purpose gauge that is serviceable and pulsation resistant
- 1/8" dial sizes
- Dampened movement combined with a flutterless pointer
- Removable lens
- Zero-adjustment
- ASME B40.100 compliant
- CRN registered
- ?2-1-2% accuracy
- Suitable for non-clogging and non-corroding media
Specification
| Dial | 1.5" (40mm) |
| Case | Steel |
| Lens | Acrylic, threaded |
| Socket | Brass |
| Connection | 1/8" Back (CB) |
| Bourdon Tube | Phosphor bronze |
| Movement | Brass (flutterless) with zero adjustment |
| Pointer | Aluminum, black |
| Over-pressure Limit | 25% of full scale value |
| Working Pressure | Maximum 75% of full scale value |
| Ambient/Process Temperature | -40?F to 150?F (-40?C to 65?C) |
| Accuracy | ?2-1-2% ANSI/ASME Grade A |
