Winters ECONOMY 2.5" 0-15 PSI/KPA 1/4" NPT BTM PEM211
(No reviews yet)
Write a Review
Write a Review
U.S. Winter instruments
Winters ECONOMY 2.5" 0-15 PSI/KPA 1/4" NPT BTM PEM211
$21.53
- Brand
- U.S. Winter instruments
- SKU:
- PEM211
- UPC:
- 6.28E+11
- Availability:
- In Stock
Winters PEM211 Offers
Features
- Friction bezel rings
- Black steel case
- Brass wetted parts
- ?3-2-3% accuracy
- ASME B40.100 compliant
- CRN registered
Applications
- Plumbing
- Heating
- Air conditioning
- Pneumatic
- Hydraulic
- Water tanks
- Air compressors
- OEM
- Water systems
- Non-clogging and non-corroding media
Winters PEM211 Specifications
| Pressure Range | 0 to 15 psi/kPa |
| Dial | 2.5" (63 mm) white aluminum with black and red markings |
| Case | Steel, painted black |
| Lens | Acrylic |
| Ring | Steel, chrome plated |
| Socket | Brass |
| Connection | ?" NPT bottom |
| Bourdon Tube | Phosphor bronze |
| Movement | Brass |
| Pointer | Aluminum, black |
| Welding | Silver alloy |
| Over-Pressure Limit | 25% of full scale value |
| Working Pressure | Maximum 75% of full scale value |
| Ambient/Process Temperature | -40 to 150?F (-40 to 65?C) |
| Accuracy | ?3-2-3% ANSI/ASME Grade B |
| Enclosure Rating | IP52 |
