Winters FILLED/BR 1.5"X1/8" NPT BACK 0/60 PSI/KPA PFQ1123|TestEquipmentUSA

Winters FILLED/BR 1.5"X1/8" NPT BACK 0/60 PSI/KPA PFQ1123

(No reviews yet) Write a Review

$59.98

Brand

U.S. Winter instruments

SKU:

PFQ1123

UPC:

6.28E+11

Availability:

In Stock

Description
0 Reviews

Testo 0635 9371Offers

Use this 4 inch high precision vane probe with the compatible Testo 440 multifunction measuring instrument to measure air velocity, volume flow and temperatures up to +158 ?F. Measurements are transmitted to your 440 meter via Bluetooth, up to 65 ft. When connected to the 440 Air Velocity and IAQ meter (Sold Separately), clearly structured measurement menus for volume flow enable the measuring instrument to be operated intuitively. The volume flow is precisely calculated thanks to a convenient input feature of the size and geometry of the duct cross-section. Timed and multi-point mean calculation, average volume flow, current reading and min./max. values are displayed in the measuring instrument. Pressing the button on the vane probe is a particularly useful feature to operate the measuring instrument. For example, to store individual readings for multi-point mean calculation or to start and stop measurement series for mean calculation over time, just tap the button to begin and end the measurement. This probe also includes a built in temperature sensor.

Winters PFQ1123 Specifications

Range	0/60 psi/kPa
Dial	1.5" white aluminum with black and red markings
Case	AISI 304 SS
Lens	Polycarbonate
Ring	AISI 304 SS, Crimp-On
Socket	Brass
Connection	1/8" Back (CB)
Fill Liquid	Glycerin
Bourdon Tube	1.5" (40mm) 2" (50mm): Phosphor bronze C or coil shaped for brass socket SS C or coil shaped for 316 SS socket 2.5" (63mm) 4" (100mm): Phosphor bronze or lead free phosphor bronze C or coil shaped for brass socket AISI 316 SS C or coil shaped for 316 SS socket
Movement	Brass
Pointer	Aluminum, anodized black
Welding	Brass: Silver alloy, 316SS:TIG
Over-Pressure Limit	25% for pressures up to 1,450 psi (9,998 kPa), 15% for pressures over 1,450 psi (9,998 kPa)
Socket Gasket	Buna N for two-piece internal socket seal
Fill Plug	Buna N
Lens Ring Gasket	Silicone rubber
Working Pressure	Maximum 75% of full scale value
Ambient/Process Temperature	Dry: -40 to 200?F (-40 to 93?C) Glycerin Filled: -4 to 150?F (-20 to 65?C)
Accuracy	1.5" (40mm) 2" (50mm): ?2.5% of full scale value 2.5" (63mm) 4" (100mm): ?1.5% of full scale value
Enclosure Rating	IP65
