Winters FILLED/SS 4" 0-600 PSI/KPA 1/2" NPT BOTTOM PFP663
$242.49
- Brand
- U.S. Winter instruments
- SKU:
- PFP663
- UPC:
- 6.28311E+11
Winters, PFP663, PFP Premium Stainless Steel Liquid Filled Gauge, Dual Scale, Dial 4", 1/2" Bottom, SS Internals, 0/600 psi/kPa
Outdoor and severe ambient and process conditions. Use where harmful vibration and pulsation are present. Hydraulic equipment, oil field equipment, pumps, compressors and process industries.
Features:
- Liquid filled stainless steel case protects against vibration and pulsation
- Bayonet ring
- Highly accurate
- Bottom mounted
- Under and overload stops
- Ventable plug on 4" stainless steel bottom mount
- Stainless steel internals
- ASME B40.100 compliant
Pressure Range | 0/600 psi/kPa |
Dial | 4" (100mm) white aluminum with black and red markings |
Case | AISI 304 SS |
Lens | Polycarbonate |
Ring | AISI 304 SS |
Socket | 316L SS. Welded one-piece socket |
Connection | 1/2" NPT |
Bourdon Tube | 316L SS, drawn seamless |
Movement | 304 SS (under and overload stops 4" to 6") |
Pointer | Aluminum, anodized black, micrometer adjustable |
Welding | Laser welded socket to case |
Fill Liquid | Glycerin |
Over-pressure Limit | 25% |
Socket Gasket | Welded (no gasket) |
Fill Plug | Buna N (silicone rubber option) |
Lens Ring Gasket | Buna N (silicone rubber option) |
Working Pressure | Maximum 75% of full scale value |
Ambient Temperature |
|
Process Temperature | -40degF to 250degF (-40degC to 120degC) |
Accuracy | +/-1% ANSI/ASME Grade 1A |
Enclosure Rating | NEMA 4X/IP66, EN60529-1 (IEC529-1) |
