Winters LOW PRESS 6" 0-32" H20 VAC 1/4 SS BTM PLP4321V
(No reviews yet)
Write a Review
Write a Review
U.S. Winter instruments
Winters LOW PRESS 6" 0-32" H20 VAC 1/4 SS BTM PLP4321V
$1,188.79
- Brand
- U.S. Winter instruments
- SKU:
- PLP4321V
- UPC:
- 6.28E+11
Winters, PLP4321V, PLP 6" Dial, 0/32" Water/Vac, 1/4" NPT Bottom SS Low Pressure Gauge
Features:
- Highly accurate reading of low pressures
- Stainless steel wetted parts
- Ranges from 15" H2O/oz to +10 PSI
- Overpressure protection on some models (OP)
- ASME B40.100 compliant
- CRN registered
Applications:
- Suitable for measuring gaseous media both corrosive and non-corrosive
- Used to measure natural gas pressure as well air flow indication and leak detection
- Vacuum pumps, air compressors, air filters, gas burners, vacuum ovens, suction regulators and respirators
| Range Scale | 0/32" Water/Vac Bottom |
| Dial | 6" (150mm), white aluminum with black and red markings |
| Case | Cast aluminum, painted black |
| Lens | Glass |
| Ring | Aluminum |
| Socket | Brass |
| Connection | 1/4" NPT standard |
| Diaphragm Element | AISI 316 SS |
| Movement | AISI 316 SS |
| Pointer | Aluminum, anodized black |
| Welding | TIG |
| Working Pressure | 75% of full scale value |
| Over-pressure Limit | 30% of full scale value |
| Ambient/Process Temperature | -40?F to 150?F (-40?C to 65?C) |
| Accuracy | ?1.6% of full scale |
| Enclosure Rating | IP52 |
