Winters LOW PRESSURE 2.5" 0-55" H20 VAC 1/4 BACK PLP342V
(No reviews yet)
Write a Review
Write a Review
U.S. Winter instruments
Winters LOW PRESSURE 2.5" 0-55" H20 VAC 1/4 BACK PLP342V
$107.56
- Brand
- U.S. Winter instruments
- SKU:
- PLP342V
- UPC:
- 6.28311E+11
Features:
- Suitable for measuring gaseous media both corrosive and non-corrosive
- Used to measure natural gas pressure as well air flow indication and leak detection
- Vacuum pumps, air compressors, air filters, gas burners, vacuum ovens, suction regulators and respirators
- Highly accurate reading of low pressures
- Brass or stainless steel wetted parts
- Overpressure protection on some models (OP)
- ASME B40.100 compliant
- CRN registered
| Dial | 2.5" (63mm) |
| Case | Steel |
| Lens | Polycarbonate |
| Socket | Brass |
| Connection | 1/4" Back (CB) |
| Diaphragm Element | AISI 316 SS |
| Pointer | Aluminum, anodized black |
| Enclosure Rating | IP52 |
| Movement | AISI 316 SS |
