Winters LOW PRESSURE 2.5" ST/ST 0-5 PSI/KPA BTTM PLP354
(No reviews yet)
Write a Review
Write a Review
U.S. Winter instruments
Winters LOW PRESSURE 2.5" ST/ST 0-5 PSI/KPA BTTM PLP354
$611.96
- Brand
- U.S. Winter instruments
- SKU:
- PLP354
- UPC:
- 6.28E+11
Description:
Winters, PLP354, PLP 2.5", 0/5 PSI/kPa, 1/4" SS Bottom Low Pressure Gauge
Features:
- Highly accurate reading of low pressures
- Stainless steel wetted parts
- Ranges from 15" H2O/oz to 10 PSI
- Overpressure protection on some models (OP)
- ASME B 40.100 compliant
- CRN registered
Applications:
- Suitable for measuring gaseous media both corrosive and non-corrosive
- Used to measure natural gas pressure as well as air flow indication and leak detection
- Vacuum pumps, air compressors, air fi lters, gas burners, vacuum ovens, suction regulators and respirators
Specification
| Pressure Range | 0-5 PSI/kPa |
| Dial | 2.5" (63mm) |
| Case | AISI 304 SS |
| Lens | Polycarbonate |
| Ring | No ring |
| Socket | AISI 316 SS |
| Connection | 1/4" NPT standard |
| Diaphragm Element | AISI 316 SS |
| Movement | AISI 316 SS |
| Pointer | Aluminum, anodized black |
| Welding | TIG |
| Working Pressure | 75% of full scale value |
| Over-pressure Limit | 30% of full scale value |
| Ambient/Process Temperature | -40?F to 150?F (-40?C to 65?C) |
| Accuracy | ?1.6% of full scale |
| Enclosure Rating | IP52 |
