Winters LOW PRESSURE 6" 0-55" H20/OZ 1/4 SS BACK PLP4362
(No reviews yet)
Write a Review
Write a Review
U.S. Winter instruments
Winters LOW PRESSURE 6" 0-55" H20/OZ 1/4 SS BACK PLP4362
$1,260.34
- Brand
- U.S. Winter instruments
- SKU:
- PLP4362
- UPC:
- 6.28E+11
Winters, PLP4362, PLP 6" 0-55" Water/oz 1/4" NPT Back SS Low Pressure Gauge
Applications:
- Suitable for measuring gaseous media both corrosive and non-corrosive
- Used to measure natural gas pressure as well air flow indication and leak detection
- Vacuum pumps, air compressors, air filters, gas burners, vacuum ovens, suction regulators and respirators
Description & Features:
- Highly accurate reading of low pressures
- Stainless steel wetted parts
- Ranges from 15" H2O/oz to +10 psi
- Overpressure protection on some models (OP)
- ASME B40.100 compliant
- CRN registered
| Specifications | Stainless Steel Internals | Brass Internals |
| Dial | 2.5" (63mm), 4" (100mm), 4.5" (115mm) and 6" (150mm), white aluminum with black and red markings | 2.5" (63mm), 4" (100mm), 4.5" (115mm) and 6" (150mm), white aluminum with black and red markings |
| Case | 2.5" (63mm), 4" (100mm): AISI 304 SS4.5" (115mm), 6" (150mm): Aluminum, painted black | 2.5" (63mm), 4" (100mm): Steel, painted black4.5" (115mm), 6" (150mm): Cast aluminum, painted black |
| Lens | 2.5" (63mm), 4" (100mm): Polycarbonate4.5" (115mm), 6" (150mm): Glass | 2.5" (63mm), 4" (100mm): Polycarbonate4.5" (115mm), 6" (150mm): Glass |
| Ring | 2.5" (63mm), 4" (100mm): No ring4.5" (115mm), 6" (150mm): Aluminum | 2.5"(63mm): No ring4" (100mm): Steel4.5" (115mm), 6" (150mm): Aluminum |
| Socket | AISI 316 SS | Brass |
| Connection | 1/4" NPT standard | 1/4" NPT standard |
| Diaphragm Element | AISI 316 SS | Phosphor bronze |
| Movement | AISI 316 SS | 2.5" (63mm): Engineering plastic upper and lower plate with brass pinion and sector;4" (100mm), 4.5" (115mm), 6" (150mm): Brass |
| Pointer | Aluminum, anodized black | Aluminum, anodized black |
| Welding | TIG | Solder/brazed |
| Working Pressure | 75% of full scale value | 60% of full scale value (fluctuating) 75% of full scale value (static) |
| Over-pressure Limit | 30% of full scale value | 30% of full scale value |
| Ambient/Process Temperature | -40?F to 150?F (-40?C to 65?C) | -40?F to 150?F (-40?C to 65?C) |
| Accuracy | +/-1.6% of full scale | +/-3-2-3% ANSI/ASME Grade B |
| Enclosure Rating | IP52 | IP52 |
0 Reviews Hide Reviews Show Reviews
U.S. Winter instruments
Winters LOW PRESSURE 6" 0-55" H20/OZ 1/4" SS BTM PLP4322
$1,188.79
Winters, PLP4322, PLP 6" Dial, 0/55" Water/oz, 1/4" NPT Bottom SS Low Pressure GaugeFeatures:Highly accurate reading of low pressuresStainless steel wetted partsRanges from 15" H2O/oz to +10...
U.S. Winter instruments
Winters LOW PRESSURE 6" 0-30" H20/OZ 1/4 SS BACK PLP4361
$1,260.34
LOW PRESSURE 6" 0-30" H20/OZ 1/4 SS BACK
U.S. Winter instruments
Winters LOW PRESSURE 4" 0-55"H20/OZ 1/4" BR BACK PLP4232
