Winters QUAL FILLED/SS 4"x1/2"NPT BACK 0/30"VAC/KPA PFQ1559

(No reviews yet) Write a Review

$225.17

Current Stock:

Quantity:

Adding to cart… The item has been added

Features

Applications

Ideal for pumps, compressors, hydraulic presses, machinery, pneumatic equipment and motors in harsh environments
Use where harmful vibration and pulsation are present
Lead free version for potable water systems

Range	30" Hg Vac/kPa
Dial	4" (100 mm)
Case	AISI 304 SS
Lens	Polycarbonate
Ring	AISI 304 SS, crimp-on
Socket	AISI 316 SS with restrictor screw (dual scale only)
Connection	0.44"-20 SAE, lower mount
Fill Liquid	Glycerin
Bourdon Tube	C-shaped for pressures up to and including 600 psi, spiral for pressures above 1,000 psi
Movement	C-shaped for pressures up to and including 600 psi, spiral for pressures above 1,000 psi
Pointer	Aluminum, anodized black
Welding	Brass: silver alloy 316 SS: TIG
Over-Pressure Limit	25% for pressures up to 1,450 psi (9,998 kPa) 15% for pressures over 1,450 psi (9,998 kPa)
Socket Material	Buna N for 2-piece internal socket seal
Fill Plug	Buna N
Lens Ring Gasket	Silicone rubber
Working Pressure	Maximum 75% of full-scale value
Ambient/Process Temperature	Dry: -40 to 200?F (-40 to 93?C) Glycerin filled: -4 to 150?F (-20 to 65?C)
Accuracy	?1.5% of full scale
Enclosure Rating	IP65
