Winters SS 4" 0-30"HG VAC 1/4" NPT BACK WITH STABILIZR(tm) PFP1090ZRR1
(No reviews yet)
Write a Review
Write a Review
U.S. Winter instruments
Winters SS 4" 0-30"HG VAC 1/4" NPT BACK WITH STABILIZR(tm) PFP1090ZRR1
$290.14
- Brand
- U.S. Winter instruments
- SKU:
- PFP1090ZRR1
- UPC:
- 6.28311E+11
Winters, PFP1090ZRR1, PFP-ZR Premium Stainless Steel StabiliZR Gauge, Single Scale, Dial 4", 1/4" Back, 30" Hg Vac/kPa
Outdoor and severe ambient and process conditions. Use where harmful vibration and pulsation are present. Hydraulic equipment, oil field equipment, pumps, compressors and process industries.
Features:
- StabiliZR dampened movement minimizes effects of pulsation and vibration as effectively as liquid filled gauges
- Stainless steel case
- Under and overload stops 4"
- Back mounted
- 316L SS wetted parts
- ASME B40.100 compliant (EN837-1 available)
- CRN registered
| Pressure Range | 30" Hg Vac/kPa |
| Dial | 4" (100mm) white aluminum with black and red markings |
| Case | AISI 304 SS (dry) |
| Lens | Polycarbonate |
| Ring | AISI 304 SS bayonet |
| Socket | 316L SS |
| Connection | 1/4" NPT |
| Bourdon Tube | 316L SS |
| Movement | 304 SS, (under and overload stops 4" and 6") and StabiliZR dampened movement (silicone in sealed chamber) |
| Pointer | Aluminum, anodized black, micrometer adjustable |
| Welding | Laser welded socket to case |
| Fill Liquid | Glycerin |
| Over-pressure Limit | 25% |
| Lens Ring Gasket | Buna N |
| Ambient Temperature | -40?F to 250?F (-40?C to 120?C) |
| Process Temperature | -40?F to 250?F (-40?C to 120?C) |
| Working Pressure | Maximum 75% of full scale value |
| Accuracy | ?1% ANSI/ASME Grade 1A |
| Enclosure Rating | NEMA 4X/IP66, EN60529-1 (IEC529-1) |
0 Reviews Hide Reviews Show Reviews
U.S. Winter instruments
Winters SS 4" 0-30"HG/KPA VAC 1/4" NPT BACK WITH STABILIZR(tm) PFP1090ZR
$290.14
Winters, PFP1090ZR, PFP-ZR Premium Stainless Steel StabiliZR Gauge, Dual Scale, Dial 4", 1/4" Back, 30" Hg Vac/kPaOutdoor and severe ambient and process conditions. Use where harmful vibration and...
U.S. Winter instruments
Winters SS 4" 0-30"HG VAC 1/4" NPT BTM WITH STABILIZR(tm) PFP640ZRR1
$263.79
Winters, PFP640ZRR1, PFP-ZR Premium Stainless Steel StabiliZR Gauge, Single Scale, Dial 4", 1/4" Bottom, 30" Hg VacOutdoor and severe ambient and process conditions. Use where harmful vibration and...
U.S. Winter instruments
Winters SS 4" 0-30"HG/KPA VAC 1/2" NPT BACK WITH STABILIZR(tm) PFP2308ZR
$290.14
SS 4" 0-30"HG/KPA VAC 1/2" NPT BACK WITH STABILIZR(tm)
U.S. Winter instruments
Winters SS 4" 0-30"HG/KPA VAC 1/4" NPT BTM WITH STABILIZR(tm) PFP640ZR
$263.79
Winters, PFP640ZR, PFP-ZR Premium Stainless Steel StabiliZR Gauge, Dual Scale, Dial 4", 1/4" Bottom, 30" Hg Vac/kPaOutdoor and severe ambient and process conditions. Use where harmful vibration and...
U.S. Winter instruments
Winters SS 4" 0-30"HG VAC 1/2" NPT BTM WITH STABILIZR(tm) PFP655ZRR1
