Winters SS 4.5" SAFETY 0/30"VAC/KPA 1/2" BTM, DRY PSC4888
(No reviews yet)
Write a Review
Write a Review
U.S. Winter instruments
Winters SS 4.5" SAFETY 0/30"VAC/KPA 1/2" BTM, DRY PSC4888
$632.56
- Brand
- U.S. Winter instruments
- SKU:
- PSC4888
- UPC:
- 6.28311E+11
Winters, PSC4888, PSC 4.5", 0/30" Vac/kPa, 1/2" SS Bottom Safety Case Gauge
Features:
- Solid front blowout back for the ultimate in gauge safety
- Full rotary movement and micrometer pointer for ease in calibration
- Overload stop
- Stainless steel case, socket and internals
- Safety glass lens
- Restricted orifi ce standard
- ASME B 40.100 compliant (EN837-1 available)
- CRN registered
- 5 year warranty
Applications:
- Used where operator safety is a must
| Pressure Range | 0/30" Vac/kPa |
| Dial | 4.5" (115mm) white aluminum with black and red markings |
| Case | 304 SS case with blowout back |
| Lens | Tempered safety glass |
| Ring | SS bayonet |
| Socket | 316L SS |
| Connection | 1/2" NPT, bottom |
| Bourdon Tube | 316L SS |
| Movement | 304 SS with overload stop |
| Pointer | Aluminum, anodized black, micrometer adjustable |
| Working Pressure | Maximum 75% of full scale value |
| Over-Pressure Limit | 25% for pressures up to 1,450 PSI (9,998 kPa), 15% for pressures over 1,450 PSI (9,998 kPa) |
| Ambient/Process Temperature | -40?F to 150?F (-40?C to 65?C) |
| Accuracy | ?0.5% ANSI/ASME Grade 2A |
| Enclosure Rating | IP65 per EN60529-1 (IEC529-1) |
