AEMC Fault Mapper Model CA7024


Product Description

AEMC Fault Mapper Model CA7024 The Fault Mapper Model CA7024 is a hand-held, alphanumeric, TDR Time Domain Reflectometer Cable Length Meter and Fault Locator, designed to measure the length of electrical and communication cables. It can also indicate the distance to a fault in the cable open or short, given access to only one end of a two or more conductor cable.By incorporating fast-edge step TDR technology, the Model CA7024 measures cable length and indicates the distance to open or short circuit faults to a range of 6000' (2000m), on at least two conductors. The Model CA7024 indicates the cable length or fault distance and description, alphanumerically on a 128 x 64 graphical LCD.   Range (@ Vp=70%) 6000ft (2000m) Accuracy 2% ± of Reading Resolution 0.1 ft up to 100 ft, then 1 ft (0.1m up to 100m, then 1m) Minimum Cable Length 12 ft (4m) Cable Library Built-in, user selectable and user programmable Velocity of Propagation (Vp) Adjustable from 0 to 99% Output Pulse 5V (peak to peak) into open circuit, nanosecond rise Step Function Output Impedance Automatic compensation Display Resolution 128x64 pixel graphical LCD Backlight Blue electroluminescent Tone Generator Oscillating 810 to 1110Hz Tone Receiver/Cable Tracer Model TR03- Available as an accessory (not included) Voltage Warning Triggers at >10VAC/DC Power Source 4 x 1.5V AA alkaline batteries (included) Auto Power Off After three minutes Dimensions 6.5 x 3.5 x 1.5” (165 x 90 x 37mm) Weight 12oz (350g) Operation Temperature  32° to 112°F (0° to 44°C) Storage Temperature   -4° to 158°F (-20 to 70°C) Ingress Protection (IP) Rating IP54 EMC EN 61326-1 Safety Compliance IEC 61010-1, EN 60950
