GW Instek PEL-3211H 2100 W/800V Booster Unit [for use with PEL-3111H

(No reviews yet) Write a Review

$6,696.00

Brand: GW Instek
SKU:: PEL-3211H
UPC:
Availability:: In Stock

Current Stock:

Quantity:

Adding to cart… The item has been added

Description
0 Reviews

Description

The Instek PEL3211H Booster is designed to be used with the PEL-3111H Electronic Load for parallel load applications to increase the current sinking capacity. Up to 4 booster packs can be connected as slave units to a PEL-3111H, which acts as the master unit.

Specification:

Booster Unit (Cannot Operate Alone)
800V/105A/2100W
Operating Mode: C.C / C.V / C.R / C.P / CC+CV / CR+CV / CP+CV
Parallel Connection of Inputs for Higher Capacity (Max. 9,450W)
Support of High Slew Rate: Max. 0.84A/us
Run Program Function (GO/NO GO Test)
Sequence Function for High Efficient Load Simulations
Dynamic (Switching) Function: 0.0166Hz -20kHz
Soft Start Function: Off / On (1-200ms, Res: 1ms)
Adjustable OCP / OVP / OPP / UVP Setting
Short Circuit Function
Timer function: Elapsed Time of load on
Cut Off Time (Auto Load Off Timer): 1s to 999h 59min 59s or Off
External Channel Control / Monitoring via Analog Control Connector
Setup Memories: 100 sets
3.5 Inch TFT LCD Display
Multi Interface: USB 2.0 Device / Host , RS-232 , GPIB (Optional)
