Mitutoyo 2416S-06 Dial Indicator

$139.81
SKU:
2416S-06
Brand:
Quantity:

Product Description

Product Description

2416S-06 Mitutoyo Series 2 Dial Indicator Standard Type: 0-1"

The Mitutoyo 2416S-06 Standard Type Dial Indicator has the following specifications:

  • Range: 0-1"
  • Graduation: .001"
  • Range/Rev: .1"
  • Dial Reading: 0-100
  • Type: with lug
  • Accuracy (First 2.5 Rev): +/- .001"
  • Accuracy (Overall): +/- .002"
  • Measuring force: 1.8N or less
  • Stem/Shank: 3/8"
  • Contact Point: #4-48 UNF Thread
  • Shockproof Type: N
  • Reverse Reading Type: N
  • Jeweled Bearing Type: N
  • Type: ANSI/AGD

Features:

  • Standard dial gauges having an outer frame with an outside diameter of 57mm. All types come with limit pins and an outer frame clamp as standard.
  • The outer clamp and lifting lever (optional) can be attached to either the right or left side. These parts can be easily installed and removed without tools.
  • Secured adhesion between the outer frame and crystal as well as the use of an O-ring ensure countermeasures against water and oil permeation via the front face.
  • The stem spindle is made of high-strength quench-hardened stainless steel which resists strenuous use.
  • A carbide contact point is used.
  • The grand gear uses stainless steel that is resistant to wear and deformation.
  • Application of a hard coating on the surface of the crystal makes the gauge highly scratch- and chemical-resistant
