REED Instruments R2050 THERMAL IMAGING CAMERA, 80 X 80

(No reviews yet) Write a Review

$985.50

Brand

REED Instruments

SKU:

R2050

Description
0 Reviews

REED R2050 Description

This entry-level thermal imaging camera features an 80 x 80 (6,400 pixels) infrared sensor that can detect temperatures between -4 to 662°F (-20 and 350°C). The R2050 is capable of displaying thermal and visual images on a vivid 2.8" LCD display and has the ability to take infrared and visual images and record video with audio (voice annotations).

Features

80 x 80 infrared resolution (6,400 pixels)
2.8" color LCD display
Built-in laser and white LED flashlight
5 megapixel digital camera
Video recording with voice annotations
3 image modes (infrared/visual camera/picture in picture)
Choice of 4 color palettes
Automatic level and span function
HDMI output and expandable memory (Micro SD)
Rechargeable li-ion battery
Tripod mountable for continuous long-term monitoring
Low battery indicator and auto shut off

REED R2050 Specifications

Imaging and Optical
Field of View (FOV)	17°x 17°
Minimum Focus Distance	0.5m
Thermal Sensitivity (NETD)	< 0.1°C @ +86°F (30°C) / 100 mK
Image Capture Frequency	50Hz
Focus	Manual
Measurement
Temperature Range	Low Range: -4 to 302°F (-20 to 150°C) High Range: 32 to 662°F (0 to 350°C)
Accuracy	±3.6°F (2°C) or ±2% of reading
Resolution	0.1 or 1°F/°C
Detector
Detector Type	Uncooled microbolometer, Focal plane array (FPA)
Spectral Range	8 to 14?m
IR Resolution	80 x 80 (6,400 pixels)
Image Presentation
Display	2.8" color (240 X 320 pixels)
Image Modes	IR image, visual image, picture in picture
Color Palettes	4 (Gray / Gray Inverted / Iron / Rainbow)
Measurement Analysis
Spot Meter	Center
Emissivity	Adjustable (0 to 1.00)
Automatic Hot/Cold Detection	Auto hot or cold spotmeter markers
Measurement Corrections	Emissivity, reflected temperature
General Specifications
Zoom	32x continuous, digital zoom
Digital Camera	5 Megapixels
Image Format	JPEG on memory card >2000 pictures
Video Out	HDMI
Video Camera and Annotations	Yes
Laser Indicator	Yes
LED Flashlight	Yes
External Memory	Micro SD card
Auto Shut-off	Yes
Tripod Mountable	Yes
Low Battery Indicator	Yes
Power Supply	Rechargeable li-ion battery
Battery Life	Approx. 4 hours
Charging System	In Camera (AC Adapter)
PC Connectivity	USB Cable
Software	Yes (Included)
Software OS Compatibility	Windows XP / 7 / 8 / 10
Supported Languages	English, Chinese, French, German, Spanish
Laser Class	II
Product Certifications	CE, IP65, 6.6' (2m) drop test
Operating Temperature	-4 to 122°F (-20 to 50°C)
Storage Temperature	-40 to 158°F (-40 to 70°C)
Operating/Storage Humidity Range	10 to 90%
Dimensions	8.8 x 3 x 7.8" (224 x 77 x 96mm)
Weight	1.1lbs (500g)
