REED R5002-NIST Digital High Voltage Insulation Tester, includes Traceable Certificate

(No reviews yet) Write a Review

MSRP: $1,155.00

$1,004.00

(You save $151.00 )

Brand: REED Instruments
SKU:: R5002-NIST
UPC:
Availability:: In Stock

Current Stock:

Quantity:

Adding to cart… The item has been added

Description
0 Reviews

Description

REED Instruments, R5002-NIST, High Voltage Insulation/Resistance Tester with NIST Certificate

R5002-NIST Includes Only:

Digital High Voltage Insulation Tester
Test Leads
Alligator Clips
AC Adapter
Batteries
Hard Carrying Case

This high voltage insulation tester is capable or testing voltages up to 5000V and measures insulation resistance up to 60G?. The R5002 performs a spot insulation test by applying a regulated and stabilized voltage to measure the amount of flowing current and then calculates resistance in order to evaluate insulation integrity.

Features:

Test Voltages of 500V, 1000V, 2500V, and 5000V
Measure Insulation Resistance to 60G?
Backlit LCD display with analog bargraph
Timer function for insulation resistance measurements (1 to 15min)
AC/DC Voltage from 0 to 600V with Max/Min, peak and relative functions
Polarization index measurement (PI)
Dielectric absorption ratio measurements (DAR)
Max/Min, Peak, Relative value and Data Hold functions
Cat. IV 600V safety rating
Low battery indicator and auto shut off

Specification

Test Voltage
Ranges	500V, 1000V, 2500V, 5000V
Accuracy	±2.5% of reading
Insulation Resistance
Ranges	0 to 6M?, 0 to 60M?, 0 to 600M?, 0 to 6G?, 0 to 60G?
Accuracy	±2.5% of reading
AC/DC Voltage
Range	0 to 600V
Accuracy	±1% of reading
Resistance
Range	0 to 600?
Accuracy	±1.5% of reading
General Specifications
Range Selection	Manual / Autoranging
Display	6000 count LCD display with bargraph
Max/Min, Peak, Relative and Data Hold Functions	Yes
Sampling Rate	2.5 times/sec.
Backlit Display	Yes
Analog Bargraph	Yes
Auto Power Off	Yes (after 20 minutes)
Continuity Buzzer	Yes (< 35?)
Power Supply	8 C Batteries or AC Adapter (included)
Low Battery Indicator	Yes
Fuse Protection	Yes
Overvoltage Category	CAT. IV 600V
Product Certifications	CE
Operating Temperature	32 to 104°F (0 to 40°C)
Storage Temperature	-4 to 140°F (-20 to 60°C)
Dimensions	7.8 x 5.8 x 3.4" (198 x 148 x 86mm)
Weight	3lbs (1.5kg)
